T574C
Series 3 , Compact Tractors
Engine manufacturer
55 hp
Engine power
3822 lb
Hitch lift capacity
A powerfully versatile compact tractor that gives you the best of both worlds
Take on tough jobs in tight spaces with the T574C. This tractor seamlessly combines the top features of our compact and utility ranges, balancing high power output with exceptional maneuverability for outstanding results every time.
*The current model is for illustrative purposes only. Available products, features, and specifications may vary depending on your region.
Telescopic linkages and stabilizers
Telescopic linkages allow attachments to be easily connected and swapped out without needing input from the operator cabin. Stabilizers make it possible for the tractor to adapt to attachments of varying loads, without putting too much pressure on engine productivity.
4-cylinder TYM diesel engine with high output
Equipped with a powerful, Tier 4-certified 4-cylinder engine, this tractor has an output comparable to utility tractors while maintaining the dimensions of a sub-compact tractor. The durable body and efficient engine come together to perform medium duty applications efficiently and productively.
Superior operator amenities
Fully equipped with modern amenities to maximize operator comfort, this tractor is complete with a large cup holder, wireless smartphone charging dock, multiple USB ports to charge personal devices, and a Bluetooth speaker. These features are designed to promote productivity, keeping drivers hydrated, connected, and alert during every job.
Durable power steering and axle configuration
The heavy-duty 4WD front axle enables the tractor to lift heavy loads and tow large attachments while absorbing shock and maintaining stability. Powerful hydraulics support the power steering system, which uses a dual-action mechanism with a hydraulic cylinder and tandem-type hydraulic pump.
3rd function hydraulic valve to enhance attachment capabilities
Allowing for versatile attachment handling, this tractor comes ready with a 3rd function installation kit. It can maximize the use of a bucket attachment with 4-in-1 functionality, including lifting, tilting, dumping, and grappling.
Easy maintenance and service
The hood of the tractor can be easily opened, allowing quick access to the engine and other systems for routine service and maintenance. This feature help increase the tractor’s durability and performance over time.
Equipped with features to elevate your productivity
With optimized attachment linkages and flexible controls, this Series 3 tractor has the capabilities to take on a variety of jobs. Complete with an intuitive console and a premium cabin, operators have the tools and the comfort to drive productivity.
Designed for applications in and around your property
This compact tractor boasts a sleek and rugged design, while the interiors are packed with in-cabin controls and features to minimize operator effort. Engineered for productivity inside and out, this tractor features sturdy cast iron linkages and easy to operate hydrostatic controls.
Good clearance from the ground and overhead allows you to take on uneven terrain easily, whether in a barn, under tree cover, or inside greenhouses. Equipped with high engine efficiency, impressive lift capabilities, and the option of a foldable ROPS or heated cab configuration, this tractor has the capabilities to perform light- to medium-duty jobs, all year round.
Arable Farming
Excellent for working in tight and narrow spaces, this tractor features powerful lift and leveling capabilities optimized for orchards, greenhouses, vineyards, and more.
Construction
Greater lift capabilities and gear controls help drive project completion efficiently, whether it’s a simple task like installing a mailbox or larger jobs like building a fence.
Snow Clearing
TYM tractors are equipped with better engine controls and larger fuel tanks, allowing them to perform a variety of tasks for longer periods of time, even in extreme cold conditions.
Landscaping
Greater control over engine speeds and compatibility with a range of specialized attachments allow access to narrower spaces, promoting productivity and faster results.
Tractors Model | T574C | T574 | T554C |
Engine manufacturer | TYM T2300T2 | TYM T2300T2 | Yanmar 4TNV86CT |
Engine power | 55 hp | 41 kW | 55 hp | 41 kW | 55.9 hp | 41.1 kW |
Rated engine speed | 2600 rpm | 2600 rpm | 2800 rpm |
Displacement | 139.5 cu. in. | 2286 cc | 139.5 cu. in. | 2286 cc | 127.6 cu. in. | 2091 cc |
No. of speeds | F8 x R8 | F8 x R8 | F16 x R16 |
Hitch lift capacity | 3822 lb | 1733 kg | 3822 lb | 1733 kg | 3314 lb | 1503 kg |
PTO rear | 540 rpm | 540 rpm | 540 rpm |
Fuel tank | 17.0 gal | 60 L | 17.0 gal | 60 L | 17.0 gal | 60 L |
Overall length with 3-point hitch | 141.3 in. | 3590 mm | 141.3 in. | 3590 mm | 141.3 in. | 3590 mm |
Overall width | 63.8 in. | 1620 mm | 63.8 in. | 1620 mm | 63.8 in. | 1620 mm |
Wheelbase | 76.2 in. | 1935 mm | 76.2 in. | 1935 mm | 76.2 in. | 1935 mm |
Min. ground clearance | 13.8 in. | 350 mm | 13.8 in. | 350 mm | 13.8 in. | 350 mm |
Weight with ROPS | - | 3887 lb | 1763 kg | 1730 lb | 3814 kg |
R1 Agricultural - Front | Farm Specialist 9.5-16 NHS TL 6PR | Farm Specialist 9.5-16 NHS TL 6PR | Farm Specialist 9.5-16 NHS TL 6PR |
R1 Agricultural - Rear | Farm Specialist 13.6-26 NHS TL 6PR | Farm Specialist 13.6-26 NHS TL 6PR | Farm Specialist 13.6-26 NHS TL 6PR |
Download | Technical Brochure | Technical Brochure | Technical Brochure |
