T394C Banner Mobile

T474C

Series 3 , Compact Tractors

REQUEST QUOTE
Engine Manufacturer

Engine manufacturer

48.3 hp

Engine power

2689.6 lb

Hitch lift capacity

A powerful compact tractor that helps you push the limits

Tackle challenges in tight spaces with the T474C. Compact but durable and expertly engineered for efficiency, this tractor excels in greenhouses, orchards, and other confined areas where space is limited but power can’t be compromised.

DOWNLOAD BROCHURE

*The current model is for illustrative purposes only. Available products, features, and specifications may vary depending on your region.

T474C Composition V2

Powerful features to drive tractor performance

Leverage a range of features to complete a variety of jobs, quickly and effectively. Available with a foldable ROPS or heated cabin, this Series 3 tractor keeps operators comfortable to take on challenges in warm or cold weather.

Rotate Image
Rotate Image
1. Auto throttle
1. Auto throttle
2. Auto PTO lever
2. Auto PTO lever
3. Cruise control
3. Cruise control
4. Cabin with heating and AC
4. Cabin with heating and AC
5. Single rear attachment control
5. Single rear attachment control
6. Shuttle transmission
6. Shuttle transmission

Designed for applications in and around your property

This compact tractor has enhanced lift capacities, maximizing work capabilities while maintaining one of the most compact frames. Functional design and precision engineering come together to create the ultimate tractor, from the Tier 4-certified engine and third-function ready rear hitch, to the ergonomically configured operator platform.

Use this tractor to maintain a healthy lawn, build a home garden, take care of yard work with ease, or create space for a lively home farm. Front-end loader, mid-mount mower and rear hitch linkages enable you to attach a variety of attachments and do more per cycle.

Applicaiton Bg 2

Arable Farming

Excellent for working in tight and narrow spaces, this tractor features powerful lift and leveling capabilities optimized for orchards, greenhouses, vineyards, and more.

Application Construction

Construction

Greater lift capabilities and gear controls help drive project completion efficiently, whether it’s a simple task like installing a mailbox or larger jobs like building a fence.

Application Snow Clearing

Snow Clearing

TYM tractors are equipped with better engine controls and larger fuel tanks, allowing them to perform a variety of tasks for longer periods of time, even in extreme cold conditions.

Application Landscaping V2

Landscaping

Greater control over engine speeds and compatibility with a range of specialized attachments allow access to narrower spaces, promoting productivity and faster results.

STORIES FROM THE FIELD

“My favorite feature about the tractor is the front-mount snow blower. It’s the first time I’ve ever had one of those, and it has made my life so much easier.”

Whether it's winter, summer, spring, or fall, Timmy was built to handle all seasons with ease! From clearing the snow to bush clearing, it's tough, reliable, and durable!

STORIES FROM THE FIELD
Technical Specification
Tractors Model
T474C
T474C
T474
T474
T454C
T454C
Engine manufacturer
TYM T2300N2
TYM T2300N2
Yanmar 4TNV88CR
Engine power
48.3 hp | 36 kW
48.3 hp | 36 kW46.6 hp | 34.3 kW
Rated engine speed
2600 rpm
2600 rpm
2800 rpm
Displacement
139.5 cu. in. | 2286 cc
139.5 cu. in. | 2286 cc133.6 cu. in. | 2189 cc
No. of speeds
F12xR12
F12xR12
F16xR16
Hitch lift capacity
2689.6 lb | 1220 kg
2689.6 lb | 1220 kg3314 lb | 1503 kg
PTO rear
540 rpm
540 rpm
540 rpm
Fuel tank
9.0 gal | 34 L
9.0 gal | 34 L17.0 gal | 60 L
Overall length with 3-point hitch
131 in. | 3320 mm
131 in. | 3320 mm141.3 in. | 3590 mm
Overall width
54.5 in. | 1385 mm
54.5 in. | 1385 mm63.8 in. | 1620 mm
Wheelbase
69.7 in. | 1770 mm
69.7 in. | 1770 mm76.2 in. | 1935 mm
Height to top of ROPS
-
94.5 in. | 2400 mm
-
Min. ground clearance
12.8 in. | 325 mm
12.8 in. | 325 mm13.8 in. | 350 mm
Weight with cab
3607 lb | 1636 kg
-
4233 lb | 1920 kg
Weight with ROPS
-
3289 lb | 1492 kg
-
R1 Agricultural - Front
Farm Specialist 8.0-16 NHS TL 6PR
Farm Specialist 8.0-16 NHS TL 6PR
Farm Specialist 9.5-16 NHS TL 6PR
R1 Agricultural - Rear
Farm Specialist 12.4-24 NHS TL 6PR
Farm Specialist 12.4-24 NHS TL 6PR
Farm Specialist 13.6-26 NHS TL 6PR
