F25
Series 3 , Compact Tractors
Engine manufacturer
24.5 hp
Engine power
1500 kg
Hitch lift capacity
A compact tractor that delivers comfort and performance
The F25 is a mid-sized compact tractor that’s both robust and efficient. Designed for lasting durability, this Series 3 tractor is ready to take on a range of applications with varying intensities.
*The current model is for illustrative purposes only. Available products, features, and specifications may vary depending on your region.
Eco-friendly TYM 4-cylinder Stage V engine
Equipped with a naturally aspirated engine designed and manufactured by TYM, the tractor is designed to be eco-friendly and fuel-efficient without compromising on performance.
Tilt steering wheel
The tilt steering wheel allows operators to adjust the position of the steering wheel for a more comfortable driving experience.
PTO on/off switch
Safety is a top priority. The PTO switch ensures secure operation of all tractor attachments.
LED work light (optional)
Full front and rear LED work lights facilitate safer operations, particularly in low visibility conditions such as rainy or dusty work environments, or during nighttime tasks.
Differential lock system and low turning angle
The differential lock system, activated with easily accessible levers, provides enhanced traction in slippery work environments, while a 52˚ turning angle makes operation in narrow areas much easier.
Water-separating fuel filter
The water-separating fuel filter prevents foreign substances from entering the fuel, ensuring better engine starting performance and preventing damage to the machine.
All the right features to get the job done
Complete a range of jobs with a TYM Series 3 tractor. Achieve results faster with a powerful high-torque engine, control attachments easily with a PTO switch, and stay energized with an ergonomically designed operator station.
Designed for applications in and around your property
This compact tractor has enhanced lift capacities, maximizing work capabilities while maintaining one of the most compact frames. Functional design and precision engineering come together to create the ultimate tractor, from the Stage V certified engine and third-function ready rear hitch, to the ergonomically configured operator platform.
Use this tractor to maintain a healthy lawn, build a home garden, take care of yard work with ease, or create space for a lively home farm. Front-end loader, mid-mount mower and rear hitch linkages enable you to attach a variety of attachments and do more per cycle.
Arable Farming
Excellent for working in tight and narrow spaces, this tractor features powerful lift and leveling capabilities optimized for orchards, greenhouses, vineyards, and more.
Construction
Greater lift capabilities and gear controls help drive project completion efficiently, whether it’s a simple task like installing a mailbox or larger jobs like building a fence.
Snow Clearing
TYM tractors are equipped with better engine controls and larger fuel tanks, allowing them to perform a variety of tasks for longer periods of time, even in extreme cold conditions.
Landscaping
Greater control over engine speeds and compatibility with a range of specialized attachments allow access to narrower spaces, promoting productivity and faster results.
| Tractors Model | F25  | F36 | F36C  |
Engine manufacturer | TYM T1700N6 | TYM T1700N6 | TYM T1700N6 |
Engine power | 24.5 hp | 18.3 kW | 34.7 hp | 25 kW | 34.7 hp | 26 kW |
Rated engine speed | 2100 rpm | 2600 rpm | 2600 rpm |
Displacement | 1715 cc | 104.7 cu. in. | 1715 cc | 104.7 cu. in. | 1715 cc | 104.7 cu. in. |
No. of speeds | SS: F12 x R12 HST: 3-Range | F36RN: F12 x R12 F36HN: 3-Range | F36C: F12 x R12 F36CHN: 3-Range |
Hitch lift capacity | 1500 kg | 3306 lb | 1500 kg | 3306 lb | 1500 kg | 3306 lb |
PTO rear | 540/540E rpm | 540/540E rpm | 540/540E rpm |
Fuel tank | 30 L | 7.9 gal | 30 L | 7.9 gal | 30 L | 7.9 gal |
Overall length with 3-point hitch | 3380 mm | 133.1 in. | 3380 mm | 133.1 in. | 3380 mm | 133.1 in. |
Overall width | 1626 mm | 64.02 in. | 1491 mm | 58.70 in. | 1477 mm | 58.15 in. |
Wheelbase | 1670 mm | 65.7 in. | 1670 mm | 65.7 in. | 1670 mm | 65.7 in. |
Height to top of ROPS | 2515 mm | 99.02 in. | Front-ROPS: 2462 mm | 96.93 in. ROPS: 2515 mm | 99.02 in. | - |
Min. ground clearance | 443.5 mm | 17.46 in. | 443.5 mm | 17.46 in. | 443.5 mm | 17.46 in. |
Weight with ROPS | 1431 kg | 3154.8 lb | F36RN Front-ROPS: 1531 kg | 3375lb ROPS: 1519 kg | 3349lb F36HN Front-ROPS: 1522 kg | 3355 lb ROPS: 1510 kg | 3329 lb | - |
Weight with cab | - | - | F36CN: 1570 kg | 3461.2 lb F36CHN: 1550 kg | 3417.2 lb |
R1 Agricultural - Front | 1: 7-16 6PR 2: 8-16 4PR 3: 280/70R16 4: 215/70R16 | 1: 7-16 6PR 2: 8-16 4PR 3: 280/70R16 4: 215/70R16 | 7-16, 6PR |
R1 Agricultural - Rear | 1: 11.2-24 8PR 2: 12.4-24 6PR 3: 380/85R24 4: 44x18-20 | 1: 11.2-24 8PR 2: 12.4-24 6PR 3: 380/85R24 4: 44x18-20 | 11.2-24, 8PR |
| Download | Technical Brochure | Technical Brochure | Technical Brochure |
